(32esno) Genie Gs3232 11.75m (38.5ft) W/H N Electric Scissor
(32esno) Genie Gs3232 11.75m (38.5ft) W/H N Electric Scissor
The Genie GS-3232 E-Drive Scissor Lift is designed to elevate workers and their tools to working heights of 11.78m indoors and 7.49m outside. The automatic leveling hydraulic outriggers level the machine on slopes up to 5 degrees and feature a large platform workspace with a roll-out platform extension. Capable of manoeuvring in confined indoor and outdoor sites, this is a quiet, compact, versatile machine with zero emissions and zero turning radius indoors.
POA
(Price On Application)
(Price On Application)
Not a customer? OPEN AN ACCOUNT
Features and Benefits
- Decent, tilt and motion alarm
- SmartLink dual zone control system
- Airline and AC power to the platform
- Lanyard attachment points
- Drivable at full height
- Solid non-marking tyres
Specifications and product comparison
Battery Capacity: Ah | 225 | 250 | 220 | 225 | 140 | 300 | 225 | 225 | 225 | 250 | 250 | 250 | 250 | 250 | 85 | -- | 420 |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Battery Type | AGM | AGM | DC | Lead-acid | AGM | -- | Lead Acid | Lead-acid | AGM | AGM | AGM | AGM | AGM | AGM | AGM | AGM | -- |
Distributed Capacity [Main Platform]: kg | 227 | 318 | 230 | 363 | 229 | 200 | 230 | 363 | 318 | 250 | 159 | 204 | 204 | 159 | 240 | 240 | 500 |
Drive Height [Max.]: m | 9.78 | 7.92 | 5.79 | 12.3 | 11.86 | 13.7 | 5.77 | 6.13 | 9.78 | 7.79 | 5.64 | 9.75 | 9.65 | 4.44 | 3.6 | 4.4 | 16.5 |
Drive Speed [Elevated]: mph | 0.5 | 0.6 | 0.3 | 0.3 | 0.5 | 0.5 | 0.3 | 0.5 | 0.5 | 0.6 | 0.7 | 0.6 | 0.6 | 0.7 | 0.3 | 0.5 | 0.31 |
Drive Speed [Lowered]: mph | 2 | 2 | 2.48 | 3.5 | 1.9 | 2.48 | 2.8 | 2 | 2 | 2.4 | 2.1 | 2 | 2 | 2.1 | 2.48 | 1.9 | 1.24 |
Fuel Type | Battery | Battery | Battery | Battery | Battery | Battery | Battery | Battery | Battery | Battery | Battery | Battery | Battery | Battery | Battery | Battery | Battery |
Function Speed [Lower\Raise]: Sec | Lower: 32, Raise; 58 | Lower: 32, Raise: 54 | Lower: 26, Raise: 25 | Lower: 28, Raise: 61 | Lower: 41, Raise: 68 | Lower: 60, Raise: 88 | Lower: 22, Raise: 27 | Lower: 33, Raise: 41 | Lower: 34, Raise: 53 | Lower: 41, Raise: 47 | Lower: 25, Raise: 19 | Lower: 49, Raise: 59 | Lower: 30, Raise: 50 | Lower: 16, Raise: 17 | Lower: 27, Raise: 32 | Lower: 18, Raise: 25 | Lower: 50, Raise: 80 |
Gradeability: % | 25 | 30 | 25 | 35 | 25 | 25 | 25 | 30 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 | 25 |
Height [Stowed]: m | 2.44 | 2.15 | 1.76 | 2.74 | 2.53 | 2.59 | 1.98 | 2.18 | 2.44 | 2.29 | 2.13 | 2.24 | 2.39 | 2.03 | 2.03 | 2.05 | 2.65 |
Length [Stowed]: m | 2.44 | 2.31 | 2.07 | 3.12 | 2.4 | 2.84 | 1.9 | 2.44 | 2.44 | 2.32 | 1.8 | 2.31 | 2.32 | 1.8 | 1.44 | 1.49 | 3.74 |
No. of Persons [Max.] | Indoor: 2, Outdoor: 1 | Indoor: 3, Outdoor: 1 | Indoor: 2, Outside: 1 | Indoors: 3, Outdoors: 2 | 3 | 2 | Indoor: 2, Outside: 1 | Indoor: 2, Outdoors: 1 | Indoor: 2, Outdoor: 1 | 2 | Indoor: 2, Outdoor: 1 | 2 | 2 | 2 | 2 | 2 | 2 |
Platform Height [Max.]: m | Indoor: 9.78, Outdoor: 5.49 | 7.92 | 5.79 | 12.3 | 11.86 | 13.7 | 5.77 | Indoor: 6.13, Outdoor: 4.88 | Indoor: 9.78, Outdoor: 6.71 | 7.79 | 5.64 | 9.75 | 9.65 | 4.44 | 3.6 | 4.4 | 16.5 |
Platform Height [Stowed]: m | 1.32 | 1.14 | 1 | 1.65 | 1.41 | 2.05 | -- | 1.07 | 1.32 | 1.17 | 1.04 | 1.23 | 1.27 | 0.91 | 1.67 | -- | 2.24 |
Platform Length: m | 2.26 | 2.13 | 1.82 | 2.79 | 2.19 | 2.64 | 1.72 | 2.26 | 2.26 | 2.11 | 1.55 | 2.13 | 2.11 | 1.55 | 1.29 | 1.28 | 4.88 |
Platform Width: m | 0.81 | 1.07 | 0.69 | 1.6 | 1.06 | 1.12 | 0.74 | 0.81 | 1.16 | 0.71 | 0.66 | 1.07 | 1.07 | 0.81 | 0.7 | 0.76 | 1.16 |
Product Brand | Genie | Skyjack | -- | -- | -- | -- | Haulotte | -- | Genie | -- | Skyjack | Skyjack | -- | Skyjack | Dingli | Skyjack | -- |
Product Model | GS3232 | SJ4626 | -- | -- | -- | -- | Optimum 8 | -- | GS3246 | -- | SJ3219 | 4632 | -- | SJ3215 | JCPT0607DCS | SJ3014 | -- |
Voltage: v | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 24 | 48 |
Weight: kg | 2,434 | 2,132 | 1,565 | 4,966 | 2,934 | 3,180 | 1,590 | 1,832 | 2,367 | 1,900 | 1,476 | 2,302 | 2,492 | 1,148 | 880 | 820 | 7,985 |
Width: m | 0.81 | 1.17 | 0.81 | 1.75 | 1.2 | 1.25 | 0.79 | 0.81 | 1.16 | 0.81 | 0.81 | 1.17 | 1.19 | 0.81 | 0.76 | 0.76 | 1.2 |
Working Height: m | Indoor: 11.78, Outdoor: 7.49 | 9.75 | 7.79 | 14.3 | 13.69 | 15.7 | 7.77 | 8.13 | Indoor: 11.78, Outdoor: 8.71 | 9.63 | 7.74 | 11.58 | 11.48 | 6.27 | 5.6 | 6.4 | 18.5 |
Wind Force [Max.]: mph | -- | 28 | -- | -- | 28 | -- | 28 | -- | -- | 28 | 28 | 28 | 28 | 28 | -- | 28 | -- |
Input Power: W | -- | -- | -- | -- | -- | -- | 5400 | -- | -- | -- | -- | -- | -- | -- | -- | -- | -- |
